Shadow Gap Cladding

Our Timber Cladding Ranges

18 x 94mm (86mm Cover)

Vertical Shadow Gap Cladding DTC12

Profile information: 18 x 94mm (86mm Cover)

Vertical Shadow Gap Cladding is increasingly popular with stylish architecturally lead projects. When installed this vertical cladding creates a pronounced 10mm square shadow gap which uses natural sunlight to visually enhance the building. A modern and striking profile.

Available in:

18 x 144mm (136mm Cover)

Vertical Shadow Gap Cladding DTC13

Profile information: 18 x 144mm (136mm Cover)

Vertical Shadow Gap Cladding is increasingly popular with stylish architecturally lead projects. When installed this vertical cladding creates a pronounced 10mm square shadow gap which uses natural sunlight to visually enhance the building. A modern and striking profile.

Available in:

18 x 92mm (78mm Cover)

Vertical Shadow Gap Secret Nail Cladding DTC14

Profile information: 18 x 92mm (78mm Cover)

Vertical Shadow Gap Secret Nail Cladding works in the same way as standard creating a pronounced 10mm square shadow gap which uses natural sunlight to visually enhance the building but is modified to have an extended top half to the rear of the piece allowing for a nail to be covered over after fixing. A modern and striking profile free of any visible fixings.

Available in:

18 x 142mm (128mm Cover)

Vertical Shadow Gap Secret Nail Cladding DTC15

Profile information: 18 x 142mm (128mm Cover)

Vertical Shadow Gap Secret Nail Cladding works in the same way as standard creating a pronounced 10mm square shadow gap which uses natural sunlight to visually enhance the building but is modified to have an extended top half to the rear of the piece allowing for a nail to be covered over after fixing. A modern and striking profile free of any visible fixings.

Available in:

18 x 94mm (86mm Cover)

Horizontal Shadow Gap Cladding DTC16

Profile information: 18 x 94mm (86mm Cover)

Horizontal Shadow Gap Cladding is a variation of a standard shadow gap but is designed to be installed horizontally. This profile is a mix of Shadow Gap and V-Groove creating a softer 10mm wide V Shape shadow line. A modern and striking profile.

Available in:

18 x 144mm (136mm Cover)

Horizontal Shadow Gap Cladding DTC17

Profile information: 18 x 144mm (136mm Cover)

Horizontal Shadow Gap Cladding is a variation of a standard shadow gap but is designed to be installed horizontally. This profile is a mix of Shadow Gap and V-Groove creating a softer 10mm wide V Shape shadow line. A modern and striking profile.

Available in:

18 x 92mm (78mm Cover)

Horizontal Shadow Gap Secret Nail Cladding DTC18

Profile information: 18 x 92mm (78mm Cover)

Horizontal Shadow Gap Cladding works in the same way as the standard profile creating a softer 10mm wide V shape shadow line but is modified to have an extended top half to the rear of the piece allowing for a nail to be covered over after fixing. A modern and striking profile free of any visible fixings.

Available in:

18 x 142mm (128mm Cover)

Horizontal Shadow Gap Secret Nail Cladding DTC19

Profile information: 18 x 142mm (128mm Cover)

Horizontal Shadow Gap Cladding works in the same way as the standard profile creating a softer 10mm wide V shape shadow line but is modified to have an extended top half to the rear of the piece allowing for a nail to be covered over after fixing. A modern and striking profile free of any visible fixings.

Available in:

18 x 144mm (134mm Cover)

Vertical Shadow Gap Half Lap Cladding DTC20

Profile information: 18 x 144mm (134mm Cover)

Vertical Shadow Gap Half Lap Cladding is a variation of the standard profile without the Tongue & Groove. Instead the timber is rebated at the rear for each piece to slide into one another. This profile is for vertical fixing and creates a pronounced 10mm square shadow gap which uses natural sunlight to visually enhance the building. A modern and striking profile.

Available in:

18 x 144mm (134mm Cover)

Horizontal Shadow Gap Half Lap Cladding DTC21

Profile information: 18 x 144mm (134mm Cover)

Horizontal Shadow Gap Half Lap Cladding is a variation to the standard profile without the Tongue & Groove. Instead the timber is just rebated at the rear for each piece to slide into on another. This profile creates a softer 10mm wide V shape shadow line. A modern and striking profile.

Available in:

18 x 142mm (128mm Cover)

Vertical Shadow Gap Secret Nail Cladding DTC33

Profile information: 18 x 142mm (128mm Cover)

Vertical Shadow Gap Secret Nail Cladding works in the same way as standard creating a pronounced 10mm square shadow gap which uses natural sunlight to visually enhance the building but is modified to have an extended top half to the rear of the piece allowing for a nail to be covered over after fixing. A modern and striking profile free of any visible fixings. The DTC33 profile also features 3 stress relieving grooves on the reverse.

Available in:
